Product Type Features
Sealable: Yes
Material Type: Brass
Surface Treatment: Tin Plating
Automotive Terminal Wire Type: Copper
Operating Temperature Range: -30–105 ℃ [-22–221 °F]
Contact Features
Typical Current Rating: 6A
Crimp Type: F-Crimp
Terminal & Splice Type: Tab
Automotive Terminal Interface Plating: Gold (Au)
Contact Termination Area Plating Material: Tin (Sn)
Termination Features
Automotive Terminal Termination Method: Crimp
Dimensions
Material Thickness: Main Body: 0.3mm
Wire Size: 0.2-0.5mm2
Wire Insulation Diameter: 1.5 – 2.2 mm[.055 – .094 in]
Packaging
Packing Method: Reel
Packaging Quantity per Reel: 6000pcs
1 carton: 3 reels
