| Application | These cables are used on board of ships in all locations for fixed installations where cable protection is required. These cables are flame retardant, low smoke & halogen free, suitable for installations on passenger ships, as on other commercial vessels. |
| Standards | DIN 89159/98 IEC 60092-351/375/359 IEC 60332-1 IEC 60332-3-22 IEC 60754-1/2 IEC 61034 |
| Construction | |
| Conductors | Stranded copper conductor. |
| Insulation | HEPR. |
| Cabling Element | Pair. |
| Armour | Copper wire braid. |
| Outer Sheath | LSOH (SHF1). |
| Core Identification | Pair: white/ blue with printed pair number and core number. |
| Mechanical and Thermal Properties | Bending Radius for Fixed Installations: 6×OD Temperature Range: -30℃ ~ +75℃ |
Dimensions and Weight
|
Part No. |
Construction No. of cores×Cross section(mm²) |
Nominal Insulation Thickness mm |
Nominal Sheath Thickness mm |
Nominal Overall Diameter mm |
Nominal Weight kg/km |
|
MFR-M2XH-2C0.75 |
2×0.75 |
0.5 |
1.1 |
6.3 |
63 |
|
MFR-M2XH-4C0.75 |
4×0.75 |
0.5 |
1.2 |
6.7 |
84 |
